Motovedetta Guardia Costiera
Coast Guard Patrol Boat
CP 286
( Classe/Class 200/S )
Bandiera Flag Italiana - Italian
Armatore Owner Ministero della Difesa - Ministry of Defence
Corpo di appartenenza Group membership Guardia Costiera Italiana
Varo Launched
Consegnata Delivered 2003
Cantiere navale Shipyard Cantiere Rodriguez - Messina - Italy
Materiale dello scafo Hull material Alluminio - Alluminium
Compartimento Marittimo Home Port Ancona
Matricola ID Number CP 286
I.M.O.    International Maritime Organization
M.M.S.I.   Maritime Mobile Service Identify 247022100
Motto Motto
Nominativo Internazionale Call Sign I G O C -
Posizione attuale Actual position
Stazza Lorda Gross Tonnage 58 Tons
Dislocamento DWT 53 Tonn
Lunghezza Max L.o.a. 25,00 m
Larghezza Breadth 5,70 m
Immersione Draught 0,90 m
Motore principale Main Engine 3 - Isotta Fraschini V1312T 2MSL
Potenza Motori Engine Power 740 x 3 Kw ( tot. 2.220 kw )
Velocità massima Max speed 34,0 kn
Eliche di propulsione Propellers 2 - passo fisso/fixed pitch
Equipaggio Crew 8
Autonomia Range 650 mgl at 30 Kn - max 900
Armamento Armament 1 - MG 42/69 - 7,62 NATO
Unità gemelle Sister ship da CP 265 a CP 292 - 267 - 284 - 280 - 285 - 289
Inserita Posted
30.10.2015
Aggiornata al
Last updated
30.10.2015
Descrizione : La CP classe 200 è stata progettata in conformità dei requisiti della Guardia Costiera : essi sono caratterizzati da elevata velocità e ottima navigabilità.
Ne sono state costruite 28 per la Guardia Costiera italiana.
Il sistema di propulsione è composto da 2 motori diesel laterali, con eliche a passo fisso, unitamente ad un motore diesel centrale con un "Booster" a getto d'acqua. Con tale propulsione può raggiungere una velocità di 34 nodi.Lo scafo è costruito in lega di alluminio.


Description:
The CP 200 Class has been designed to comply with the Coast Guard requirements: they are characterised by high speed and excellent seaworthiness.
Built in number of 28 for the Italian Coast Guard, the CP200 FPBs have a crew of 12.
The propulsion is granted by 2 lateral diesel engines, driving fixed pitch propellers, and by one central diesel engine couplet with a “booster” waterjet: with such propulsion the can achieve a speed of 34 knots.

Le informazioni tecniche contenute in questa sche sono state reperite dal sito ufficiale del costruttore " Cantieri Rodriguez" di Messina .
The technical information contained in this cards were found from the official website of the manufacturer " Cantieri Rodriguez" of Messina.
